T二踏步板介绍

首页>>踏步板

T二踏步板介绍

T二踏步板介绍

所属分类:踏步板

点击次数:3138

发布日期:2019-10-13 08:40:44

全国服务热线:15613110663

我要询价

产品描述

钢梯踏步板也就是踏步板规格型号一般采用扁钢宽度25mm、30mm、32mm,厚度3mm、4mm、5mm,这种规格型号能满足场所的承重需求,使用起来也比较经济实惠!如

规格型号扁钢宽度扁钢厚度扁钢间距横杆间距
253/30/10025330100
303/30/10030330100
323/30/10032330100
255/30/10025530100
305/30/10030530100
325/30/10032530100


    钢梯踏步板的长度有:600mm 700mm  800mm 900mm 1000mm 1200mm,最小宽度为600mm,最大宽度不宜大于1200mm,宽度有:125mm、 155mm、 165mm、 185mm、 205mm、 215mm、 245mm、 275mm。

T2钢梯踏步板
规格型号(mm)外形尺寸(mm)重量(kg)参考价格(元/块)规格型号(mm)外形尺寸(mm)重量(kg)参考价格(元/块)
253/30/100125*6002.4928253/30/100155*6003.0330
255/30/100125*6003.7730255/30/100155*6004.5633
303/30/100125*6002.8429303/30/100155*6003.4531
325/30/100125*6004.6233325/30/100155*6005.5836
253/30/100125*7002.7929253/30/100155*7003.3831
255/30/100125*7004.2632255/30/100155*7005.1634
303/30/100125*7003.1930303/30/100155*7003.8732
325/30/100125*7005.2435325/30/100155*7006.3338
253/30/100125*8003.0930253/30/100155*8003.7432
255/30/100125*8004.7633255/30/100155*8005.7536
303/30/100125*8003.5531303/30/100155*8004.2934
325/30/100125*8005.8637325/30/100155*8007.0840
253/30/100125*9003.3831253/30/100155*9004.133
255/30/100125*9005.2535255/30/100155*9006.3438
303/30/100125*9003.932303/30/100155*9004.7235
325/30/100125*9006.4938325/30/100155*9007.8342
253/30/100185*6003.5631253/30/100215*6004.133
255/30/100185*6005.3635255/30/100215*6006.1537
303/30/100185*6004.0533303/30/100215*6004.6635
325/30/100185*6006.5539325/30/100215*6007.5141
253/30/100185*7003.9833253/30/100215*7004.5835
255/30/100185*7006.0537255/30/100215*7006.9440
303/30/100185*7004.5535303/30/100215*7005.2337
325/30/100185*7007.4241325/30/100215*7008.5244
253/30/100185*8004.434253/30/100215*8005.0536
255/30/100185*8006.7439255/30/100215*8007.7442
303/30/100185*8005.0436303/30/100215*8005.7939
325/30/100185*8008.344325/30/100215*8009.5247
253/30/100185*9004.8235253/30/100215*9005.5338
255/30/100185*9007.4441255/30/100215*9008.5344
303/30/100185*9005.5438303/30/100215*9006.3640
325/30/100185*9009.1846325/30/100215*90010.5250
253/30/100245*6004.6335253/30/100275*6005.1737
255/30/100245*6006.9440255/30/100275*6007.7442
303/30/100245*6005.2737303/30/100275*6005.8739
325/30/100245*6008.4844325/30/100275*6009.4547
253/30/100245*7005.1737253/30/100275*7005.7739
255/30/100245*7007.8442255/30/100275*7008.7345
303/30/100245*7005.939303/30/100275*7006.5841
325/30/100245*7009.6147325/30/100275*70010.751
253/30/100245*8005.7138253/30/100275*8006.3741
255/30/100245*8008.7345255/30/100275*8009.7248
303/30/100245*8006.5441303/30/100275*8007.2944
325/30/100245*80010.7451325/30/100275*80011.9554
253/30/100245*9006.2540253/30/100275*9006.9743
255/30/100245*9009.6247255/30/100275*90010.7151
303/30/100245*9007.1843303/30/100275*900846
325/30/100245*90011.8654325/30/100275*90013.2158
253/30/100245*10006.7942



255/30/100245*100010.5150



303/30/100245*10007.8145



325/30/100245*100012.9957



253/30/100275*10007.5744



255/30/100275*100011.7153



303/30/100275*10008.748



325/30/100275*100014.4661
